Specifications in detail
Main Unit
Machine Type
Monochrome Laser Multifunctional
Core Functions
Print, Copy, Scan, Send and Fax
Processor Speed
Cortex-A9MPCore 800MHz脳2
Control Panel
12.7cm (5 inch) TFT LCD WVGA Colour Touch panel
Memory
Standard: 1.0GB RAM
Storage
2GB (eMMC)
Interface Connection
NETWORK Standard:
1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection
OTHERS Standard:
USB 2.0 (Host) x2, USB 2.0 (Device) x1
Paper Supply Capacity (A4, 80 gsm)
Standard: 650 sheets
Paper Cassette: 550-sheet
Multi-purpose tray: 100-sheet
Maximum: 2,300 sheets (with PAPER FEEDER PF-C1x3)
Paper Output Capacity (A4, 80 gsm)
150 sheets
Finishing Capabilities
Collate, Group
Supported Media Types
Upper Cassette 1:
Thin, Plain, Thick, Colour, Recycled, Bond
Multi-purpose tray:
Thin, Plain, Thick, Colour, Recycled, Bond, Label, Envelope
Supported Media Sizes
Upper Cassette 1:
Standard size: A4, B5, A5, A5R, A6
Custom size: Min. 105.0 x 148.0 mm up to 216.0 x 355.6 mm
Multi-purpose tray:
Standard size: A4, B5, A5, A5R, A6
Index Card, Envelopes [No. 10 (COM 10), Monarch, ISO-C5, DL]
Custom Size: Min. 76.2 x 127.0 mm up to 216.0 x 355.6 mm
Supported Media Weights
Custom Size: Min. 76.2 x 127.0 mm up to 216.0 x 355.6 mm
Upper Cassette 1: 60 to 120 gsm
Multi-purpose tray: 60 to 199 gsm
Duplex: 60 to 120 gsm
Warm-up Time
From Power On: 14 Seconds or Less*
* Time from device power-on, until copy ready (not print reservation)
From Sleep Mode: 4 Seconds or Less
Dimensions (W x D x H)
480 x 464 x 452 mm
Installation Space (W x D)
480 x 905 mm (with Cassette open)
Weight
Approx. 19.0 kg (without toner)
Print Specifications
Print Speed
1-sided:
Up to 43/43 ppm (A4)
2-sided:
Up to 36/36 ppm (A4)
Print Resolution (dpi)
Up to 1200 x 1200
Page Description Languages
Standard: UFR II, PCL6, PCL5, Adobe庐 PostScript3
Direct Print
Direct printing available from USB memory, LPR Supported file types: TIFF, JPEG, PDF and XPS (only LPR)
Mobile / Cloud Printing
Apple AirPrint, Canon PRINT Business, Mopria, Canon Print Service, Dropbox, GoogleDrive, OneDrive and uniFLOW Online
A range of software solutions is available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
Fonts
PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Barcode fonts
PS fonts: 136 Roman
Print Features
Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/Orientations, Toner Reduction, Poster Printing, Print Date
Operating Systems
UFRII: Windows庐 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.11 or later)
PCL: Windows庐 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019
PS: Windows庐 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019, MAC OS X (10.11 or later)
PPD: Windows庐 8.1/1011, MAC OS X (10.11 or later)
Copy Specifications
Copy Speed
1-sided:
Up to 43/43 ppm (A4)
2-sided:
Up to 36/36 ppm (A4)
First-Copy-Out Time
Platen: Approx. 6.3 seconds or less
ADF: Approx. 6.4 seconds or less
Copy Resolution (dpi)
600 x 600
Multiple Copies
up to 999 copies
Copy Density
Automatic or Manual (9 Levels)
Magnification
25% - 400% (1% Increments)
Preset Reductions
25%, 50%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200%, 400%
Preset Enlargements
25%, 50%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200%, 400%
Basic Copy Features
Preset R/E Ratios by Area, Paper Setting, Favourite Setting, Two-Sided, Density Adjustment, Original Type Selection
Special Copy Features
Two-sided Original, Job Build, N on 1, Different Size Originals, Density Adjustment, Original Type Selection, Sharpness, Erase Frame, Job Done Notice, Copy ID Card, Collate
Scan Specifications
Type
Standard: Single-Pass Duplexing Automatic Document Feeder
Pull Scan Specifications
ScanGear MF For both TWAIN and WIA Windows庐8.1 /10/11, Mac OS X (10.11 orlater)
Scan Resolution (dpi)
Scan for Copy: up to 600 x 600
Scan for Send: (Push) up to 300 x 600, (Pull) up to 600 x 600
Scan for Fax: up to 400 x 400
Document Feeder Paper Capacity (80 gsm)
up to 50 sheets (A4, 80gsm)
Acceptable Originals/Weights
Platen: Sheet, Book, 3-Dimensional Objects (Height: up to 20mm)
Document Feeder sheet media weight: 1-sided/2-sided
Continuous Scanning: 50 to 105 gsm
Supported Media Sizes
Sheet media size: A4R, B5R, A5R, A6R
Custom size: 105 x 128 mm to 215.9 x 355.6 mm
Scan Method
Push scan, Pull scan, Scan to Network, Scan to memory media (USB Memory Key), Scan to cloud-based services (Dropbox, GoogleDrive, OneDrive, uniFLOW Online)
Scan Speed
DADF Send (ipm, A4):
1-sided Scanning (BW/CL): 38/13
2-sided Scanning (BW/CL): 70/26
DADF Copy (ipm, A4):
1-sided Scanning: 20
2-sided Scanning: 34
Send Specifications
Destination
Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV,
Optional: Super G3 FAX
Address Book / Speed Dials
LDAP (50)/Local (300)/Speed dial (281)
Send Resolution (dpi)
Push: 196 x 204 (I-FAX) 300 x 300 (email/SMB/FTP)
Pull: Max. 9600 x 9600
Communication Protocol
File: FTP (TCP/IP), SMB 3.0 (TCP/IP)
Email/iFax: SMTP (send), POP3- (recieve)
File Format
Standard: TIFF, JPEG, PDF (Compact, Searchable, Encrypted, Digital Signature, PDF/A-1b)
Universal Send Features
Original Type Selection, Two-sided Original, Density Adjustment, Sharpness, File Name, Subject/Message, E-mail Priority, TX Report, Original Content Orientation
Fax Specifications
Optional / Standard
Standard
Maximum Number of Connection Lines
1
Modem Speed
Super G3: 33.6 kbps
G3锛?14.4 kbps
Compression Method
MH, MR, MMR, JBIG
Resolution (dpi)
400 x 400 (Ultrafine), 200 x 400 (Superfine), 200 x 200 (Fine/ Photo), 200 x 100 (Normal)
Sending/Receiving Size
Sending: A4, B5
, A5, A6*
* Sent as A4
Receiving: A4, B5, A5
FAX Memory
Up to 512 pages
Speed Dials
Max. 281
Group Dials/Destinations
Max. 299 dials
Sequential Broadcast
Max. 310 addresses
Memory Backup
Yes
Fax Features
Sender's Name (TTI), Direct Send, TX Report, Sequential Broadcasting
Store Specifications
Memory Media
Standard: USB Memory
Security Specifications
Authentication & Access Control
Department ID Authentication (Department ID and PIN login, Function level Login)
uniFLOW Online (PIN Login, Card Login, Card and PIN Login)
Network Security
TLS 1.3, IPSec, IEEE802.1X authentication, SNMPv3, Firewall, Functionality (IP/MAC Address Filtering), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN
Document Security
Print Security (Secure Print, uniFLOW Secure Print*), Scan Security (Encrypted PDF, Device Signature PDF/XPS), Send Data Security (Restricted E-mail/File send functions, Security Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History)
*Requires optional uniFLOW Online / uniFLOW
Device Security
Storage Initialize, Job Log Conceal Function, Protecting MFP Software Integrity, Verify System at Start-up
Device Management & Auditing
Administrator Password, Digital Certificate and Key Management, Security Policy Setting
Environmental Specifications
Operating Environment
Temperature: 10 to 30 掳C (50 to 86 掳F)
Humidity: 20 to 80 % RH (Relative Humidity)
Power Source
AC220-240V:3.9A,50/60Hz
Power Consumption
Maximum: Approx. 1420W or less
Standby: Approx. 13.6 W
Sleep mode: Approx. 0.9 W
Plugin Off: Approx. 0.1W or less
Typical Electricity Consumption (TEC)*: 0.41kWh
*As per ENERGY STAR Version 3.0
For detailed information relating to Lot26 regulation, please go to:聽
https://www.canon-europe.com/for_work/lot26/Noise Levels
Sound Power Level (LwAd)
Active: 72.9 dB or Less*1
Standby: LwAm 3.7B, Kv 0.3B*2
Sound Pressure Level (LpAm)*2
Bystander's position:
Active: 1-sided:LpAm 54 dB, 2-sided:LpAm 53 dB
Standby: 24 dB
*1 RAL-UZ205(2017) compliant (Data taken from Blue Angel Standard value)
*2 Reference value: measured only one unit with ISO7779, described with ISO9296:2017
Standards
Blue Angel (Pending Confirmation)
Software & Printer Management
Tracking & Reporting
uniFLOW Online
Remote Management Tools
iW Enterprise Management Console
eMaintenance
Content Delivery System
Scanning Software
Network ScanGear
Consumables
Toner Cartridge/s
Toner T06 Black
Toner Estimated Yield
20,500 pages (A4)
(Estimated @ 5% coverage)
Paper Feeder
Paper feeder PF-C1
Paper Capacity: 550 sheets (80 gsm)
Paper Type: Thin, Plain, Thick, Colour, Recycled, Bond
Paper Size: A4,B5,A5,A5R,A6,
Custom size: 105.0 x 148.0mm to 216.0 x 355.6mm
Paper Weight: 60 to 120 gsm
Power Source: From the Main Unit
Dimensions (W x D x H): 480 x 464 x 842mm*
(*attached to the main unit)
Weight: Approx. 4.0 kg
Hardware Accessories
Card Readers
MiCard Attachment kit-B1
Copy Card Reader-F1
Copy Card Reader Attachment-J1
System & Controller Options
Barcode Printing
Barcode Print Kit-E1E EU
System Accessories
Control I/F Kit-C1
