The TP-Link TL-SF1024D is a 24-port 10/100Mbps desktop/rackmount switch designed for expanding wired networks. It features 24 RJ45 ports that support auto-negotiation and auto MDI/MDIX, meaning it automatically detects the cable type and speed. This switch is known for its energy-efficient technology, which can save up to 75% of power consumption. It also supports store-and-forward switching, a 4.8Gbps switching capacity, and a 3.57Mpps packet forwarding rate.
Key Specifications:
Interface: 24 x 10/100Mbps RJ45 ports with auto-negotiation and auto MDI/MDIX
Standards: IEEE 802.3, 802.3u, 802.3x
Switching Capacity: 4.8Gbps
Packet Forwarding Rate: 3.57Mpps
MAC Address Table: 8K
Buffer Memory: 2Mb
Green Technology: Energy-efficient technology saves power up to 75%
Transfer Method: Store-and-Forward
Mounting: Desktop/Rackmountable
Dimensions: 11.67.11.7 in. (29418044 mm)
Power Consumption: Max 3.2W
Fan: Fanless
Housing: Metal (13-inch steel case)
LED Indicators: Link, Power
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Humidity: 10% to 90% non-condensing
Storage Humidity: 5% to 90% non-condensing
Additional Features:
The switch is designed for easy plug-and-play installation.
It supports IEEE 802.3x flow control for reliable data transmission.
It is rack mountable, allowing for flexible installation options.
The switch is designed with energy-saving features to reduce power consumption.
