TCL - Air Conditioner (18000BTU)
Inverter
Brand: TCL
Model: TAC-18CSD
Capacity: 18000BTU
Type: Cooling Only
Control type: Remote
Rated Cooling Capacity (Btu/h): 18000 (3412 ~ 21150)
Rated Cooling Capacity (W): 5100
CSPF (Btu/h.w; W/W): 4.6
Moisture removal (Liters/h): 1.8
Indoor noise level at cooling (dB (A)):
High: 45
Med: 38
Low: 36
Outdoor noise level (dB (A)): 55
Warranty: 1 Year Warranty plus 5 Years Compressor Warranty
Power Supply:
Power Supply: 220-240V~ / 50Hz/1P
Voltage Range: 155 ~ 265V
Rated current (Cooling): 7.31 (1.6~12.0) A
Rated input (Cooling): 1700 (300 ~ 2400) W
Max current: 12 A
Max input: 2400 W
Fan System:
Indoor air circulation Cooling (m3/h): 810
Indoor fan type: Cross Flow
Indoor fan speed H/M/L:
Cooling (rpm): 830/780/730/680/620
Dry (rpm): 680
Sleep (rpm): 680
Indoor fan motor output: 25 W
Outdoor fan type: Propeller Fan
Outdoor fan speed: 860rpm
Outdoor fan motor output: 25W
Others:
Refrigerant/Charge (Gram): R32/730
Compressor:
Type: Rotary
Evaporator: 3-bend
Indoor coil:
Number of rows: 2
Tube pitch (a)x row pitch (b): 21 x 12.7mm
Fin spacing: 1.5mm
Fin type (code): Hydrophilic
Tube outside dia.and type: Ø7mm inner groove tube
Coil (length x height x width): 705 x 315 x 25.4mm
Number of circuits: 4
Condenser: double-arranged
Connecting Pipe:
Gas: 1/2''
Liquid: 1/4''
Connecting Wiring (Size x Core number): 4 x 2.5
Dimension & Weight:
Width x Depth x Height
Suitable area: 25-40 m2
Indoor Unit:
Product Dimension: 910 x 206 x 294mm (35.8” x 8.1” x 11.6”)
Packing Dimension: 979 x 292 x 372mm (38.5” x 11.5” x 14.6”) (from packing box)
Net Weight: 9kg
Gross Weight: 12kg
Outdoor Unit:
Product Dimension: 780 x 290 x 605mm (30.7” x 11.4” x 23.8”)
Packing Dimension: 835 x 340 x 628mm (32.9” x 13.4” x 24.7”)
Net Weight: 28kg
Gross Weight: 32kg
Packing Contents:
18k BTU Indoor Unit – x1
12ft. Electric wire – x1
Remote Control – x1
AAA Battery – x2
Wall Mount Remote Holder – x1
Screws with Plugs – x8
Warranty Certificate – x1
User Manual – x1
18k BTU Outdoor Unit – x1
1/4" Copper Tube (13ft.) – x1
1/2” Copper Tube (13ft.) – x1
Drainage Hose – x1
Wrapping Tape – x1
Insulation Sheath – x1
Plasticene RoHS – x1
SKU: 47093
