Car Diagnostic Scanner

1. Works with most OBD-II compliant vehicles (make sure your car supports the required protocols) 2. Wireless (Bluetooth) 3. Software included for Palm, PDA 4. Software included for Windows PC 5. Software included for Windows Smartphone 6. Supports ISO 9141, KWP2000 7. Supports SAE J1850 8. Supports CAN bus Functions: 1. Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). 2. Clear trouble codes and turn off the MIL ("Check Engine" light) 3. Display current sensor data, including: 4. Engine RPM 5. Calculated Load Value 6. Coolant Temperature 7. Fuel System Status 8. Vehicle Speed 9. Short Term Fuel Trim 10. Long Term Fuel Trim 11. Intake Manifold Pressure 12. Timing Advance 13. Intake Air Temperature 14. Air Flow Rate 15. Absolute Throttle Position 16. Oxygen sensor voltages/associated short term fuel trims 17. Fuel System status 18. Fuel Pressure Supported OBD-II protocols: 1-ISO 9141-2 (5 baud init, 10.4 Kbaud) 2-ISO14230-4 KWP (5 baud init, 10.4 Kbaud) 3-ISO14230-4 KWP (fast init, 10.4 Kbaud) 4-ISO15765-4 CAN (11bit ID, 500 Kbaud) 5-ISO15765-4 CAN (29bit ID, 500 Kbaud) 6-ISO15765-4 CAN (11bit ID, 250 Kbaud) 7-ISO15765-4 CAN (29bit ID, 250 Kbaud) For your information: For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant. Alfa Romeo/ Audi/ Bentley/ BMW/ Cadillac/ Chevrolet/ Chrysler/ Citroen/ Daewoo/ Fiat/ Ford/ GM/ Honda/ Hyundai/ Isuzu/ Jaguar/ Jeep/ Kia/ Land Rover/ Lexus/ Mazda/ Mercury/ Mini/ Nissan/ Mitsubishi/ Opel/ Peugeot/ Porsche/ Renault/ Rover/ Saab/ Seat/ Skoda/ Toyota/ Vauxhall/ Volvo/ VW Software Included: 1. Scantool_net113win (Full Version) 2. Easy OBDII V2.2 (Full Version) 3. OBD2 Spy (Demo Version) 4. Scan Master-ELM (Demo Version) 5. OBDCRAZY (Demo Version) 6. This hardware can match other software also! But most are not free. Note: Only Supports Android Phone, no support Apple iPhone Some Known cars that the scanners is not compatible are: VW Polos Fortuner Hilux Range rover Bakkies and SUV s etc. FAQ: How do I pair OBDII Scan Tool to my Android Smart phone or Tablet? 1. Make sure your car is OBD2 compatible. 2. Locate your car s OBD II diagnostic port and plug in your scanner. It s usually found under the driver s side dashboard, under the steering wheel. 3. Turn on your vehicle engine, this provides power to your dash lights, radio and also the OBD II diagnostic port. 4. From your Android Smartphone or tablet, go to your Bluetooth. Turn on Bluetooth, scan for the nearby devices and pair your phone with the scanner. Password is 1234. Bluetooth Pairing Issues: 1. Unpair any existing Bluetooth devices such as, smartwatch, headset, car Bluetooth or speakers from your phone. 2. Make sure the Torque App is not running in the background. Close the Torque app before pairing the device to your android smart phone or tablet. 3. After pairing to OBDII from your android smart phone or tablet, then open the torque app. 4. If the password 1234 doesn t work, try 12345 or 0000 5. Turn off Bluetooth, turn it back on and rescan for the device Torque Android Application Connection 1. Open your Torque OBD-II app. 2. Tap on the setting icon which is on the left bottom of the screen. 3. Tap on the Settings again. 4. Tap on OBD2 Adapter Settings. 5. Tap on Choose Bluetooth Device. 6. Tap on OBDII, to pair with the Bluetooth scanner. 7. Go back to the App s main menu to enjoy its features What's in the box 1 x MINI Bluetooth OBD2 II Diagnostic Interface Scanner Basic Colours Blue Barcode MPTAL74101205 1. Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). 2. Clear trouble codes and turn off the MIL ("Check Engine" light) 3. Display current sensor data, including: 4. Engine RPM 5. Calculated Load Value 6. Coolant Temperature 7. Fuel System Status 8. Vehicle Speed 9. Short Term Fuel Trim 10. Long Term Fuel Trim 11. Intake Manifold Pressure 12. Timing Advance 13. Intake Air Temperature 14. Air Flow Rate 15. Absolute Throttle Position 16. Oxygen sensor voltages/associated short term fuel trims 17. Fuel System status 18. Fuel Pressure Supported OBD-II protocols: 1-ISO 9141-2 (5 baud init, 10.4 Kbaud) 2-ISO14230-4 KWP (5 baud init, 10.4 Kbaud) 3-ISO14230-4 KWP (fast init, 10.4 Kbaud) 4-ISO15765-4 CAN (11bit ID, 500 Kbaud) 5-ISO15765-4 CAN (29bit ID, 500 Kbaud) 6-ISO15765-4 CAN (11bit ID, 250 Kbaud) 7-ISO15765-4 CAN (29bit ID, 250 Kbaud) For your information: For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant. Alfa Romeo/ Audi/ Bentley/ BMW/ Cadillac/ Chevrolet/ Chrysler/ Citroen/ Daewoo/ Fiat/ Ford/ GM/ Honda/ Hyundai/ Isuzu/ Jaguar/ Jeep/ Kia/ Land Rover/ Lexus/ Mazda/ Mercury/ Mini/ Nissan/ Mitsubishi/ Opel/ Peugeot/ Porsche/ Renault/ Rover/ Saab/ Seat/ Skoda/ Toyota/ Vauxhall/ Volvo/ VW Software Included: 1. Scantool_net113win (Full Version) 2. Easy OBDII V2.2 (Full Version) 3. OBD2 Spy (Demo Version) 4. Scan Master-ELM (Demo Version) 5. OBDCRAZY (Demo Version) 6. This hardware can match other software also! But most are not free. Note: Only Supports Android Phone, no support Apple iPhone Some Known cars that the scanners is not compatible are: VW Polos Fortuner Hilux Range rover Bakkies and SUV s etc.
