Model NO: IPC-PST30-XM500W
Camera
Image CMOS Sensor
1/2." SC5335P
DSP
XM550AI
Resolution 5.0M Pixel
Effective Pixels 2592(H)*1944(V)
Electronic Shutter 1/50-1/10000Sec
Motion Detection Support
Scanning System
ProgressiveSync System
ExternalPrivacy Masking
Support, Up to 4 areas
S/N Ratio ≥52dB
White Balance Auto/Manual
Gain Control. Auto/Manual
Digital Noise Reduction
Support 2D/3D
Wide Dynamic Range D-WDR
Recording Mode NVR/NAS/CMS/Web
Video and Audio
Video Compression
H.265Video Output
Main stream: 2592*1944@25fps
Audio Processing G.711,support bidrectional talk,audio&video synchronization
Audio interface 1ch input,level:2Vp p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone
(Built-in High Sensitive Microphone)
LensFocal Length3.6mm
Focus ControlFixed
Lens Type
M12
Lens Pixels
5.0M Pixels
Auto Iris Support
N/A
Night Vision
Infrared LED
4pcs Warm Light LED, 25-30M IR Range
Low illumination
0.01Lux @F2.0
0 Lux with IR LED on
Day & Night
Support IR-CUT
Network
Ethernet
RJ-45 (10/100Base-T)1*RJ45 10/100M adaptive Ethernet port
Network Protocol
support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc
ONVIF
Support ONVIF
Smart Phone
Support iPhone, iPad, Android and Windows
Browser
Support IE, Chrome, Firefox, Safari
Sotware
Support App(iOS，Android), Window CMS software
General
Housing
Plastic Dome Case, White + Black Color Housing
Working Temperature
-10℃～50℃
Weatherproof Std.
Not Support Waterproof, IP55
Dimension
Φ110x95(H) mm
Weight
0.5 Kg
