Features
• Upgrade existing switches into smart controls without changing the wiring.
• Provides reliable two-way switching support compatible with standard wiring installations.
• Control schedules, timers, and scenes conveniently through the smart app.
Technical Specifications
• Power Input: 240V AC, 50/60Hz.
• Max Current Output: Up to 16A.
• Maximum Supportive Load: 7.5KW (32A).
• Load Type:
• Incandescent lamp / Resistive load per channel: 1800W.
• LED Load: 200W or 6 Nos (whichever is higher) on each channel.
• Inductive Load: 800W.
• Typical standby power: <0.8W.
• Surge Protection: 2.5KV (Tested up to 4KV).
• Dimensions:
• Height: 52mm; Width: 16mm; Length: 56mm (1 Switch / 2 Switch).
• Height: 52mm; Width: 16mm; Length: 80mm (4 Switch).
• Height: 52mm; Width: 16mm; Length: 103mm (6 Switch).v
